The speaker driver for
Waterproof Purpose
Water and dust resistance to fit with your wearable device
The wearable devices are getting sophisticated and exquisite to fulfill men’s daily life everywhere. The wearable devices are required to keep functioned under various environmental and temperature conditions, and some of them may be very challenging. As a acoustic technology professional, our driver unit must overcome the challenges to fulfill the need of our customers.
The water resistant structure design of the driver units need to go through strict pressure test to ensure that the resistance level conforms with the expectation and will not be damaged by water or liquid to cause audio dysfunction. We can provide the best acoustic solution for your water resistant device.
#The speaker drivers are highly customized. Please contact us for more precise details.
 |
 |
Specifications
|
FG-1206E2S Size (mm)12*6*3.0 IMP (ohm)8 Rated Power (W) 0.5W (in 3cc cavity) FO (Hz) 1150Hz (in 3.0cc cavity) SPL (dB) 85±3dB (0.5w/0.1m at 2kHz in 3.0cc back cavity) IP & Water Resistant Rating 7 ATM |
FG-1208B2S-4 Size (mm)12*8.3*2.18 IMP (ohm)8 0.25W (in 0.5cc cavity) FO (Hz) 1050Hz (in 0.5cc cavity) SPL (dB) 83±3dB (0.25w/0.1m at 2kHz in 0.5cc back cavity) IP & Water Resistant Rating IP67 |
FG-1306A2S Size (mm)13*6*3.0 IMP (ohm)8 Rated Power (W) 0.6W (in 3cc cavity) FO (Hz) 900Hz (in 3.0cc cavity) SPL (dB) 86±3dB (0.6w/0.1m at 2kHz in 3.0cc back cavity) IP & Water Resistant Rating 10 ATM |
FG-1506E2S
Size (mm)15*6*2.5
IMP (ohm)8
Rated Power (W)
0.5W (in 1cc cavity)
FO (Hz)
980Hz (in 1.0cc cavity)
SPL (dB)
88±3dB (0.5w/0.1m at 2kHz in 1.0cc back cavity)
IP & Water Resistant Rating
3 ATM
|
