The speaker driver for
AIO / Smart Speaker
Space allows the pursue of the ultimate sound
When there is more space for the audio chamber, it is more for creating different sound performance. We offer the service to customize the dynamic drivers that includes the unique tuning technology. Along with the appropriate audio chamber, it comes with the sound that meet the unique expectation. Not only the good sound, we provide different and exclusive sound performance to distinguish each acoustic product.
We possess all the major facilities for acoustic simulation and quality tests. We not only focus on the sound effect but also the steadiness of the sound quality. Under the strict testing conditions, we are able to provide excellent sound performance and steady quality.
#The speaker drivers are highly customized. Please contact us for more precise details.
 |
 |
Specifications
|
FG-32QB2-1A Size (mm)Ф32*14.8h IMP (ohm)8 Rated Power (W) 4W FO (Hz) 230 Hz ±15% SPL (dB) 85.4±3dB (1W/0.5m; Average at 800,1000,1200,1500) |
FG-40FB2Size (mm)Ф40*11.5h IMP (ohm)8 Rated Power (W) 2W FO (Hz) 330HZ±15% SPL (dB) 91.5±3dB (1W/0.5m; Average at 800, 1000, 1200, 1500 Hz) |
FG-55A1-1B Size (mm)Ф55*27.1h IMP (ohm)4 Rated Power (W) 7W FO (Hz) 100 Hz ± 20% SPL (dB) 86±3dB (1W/0.5M; Average at 800, 1000, 1200, 1500 Hz) |
FG-9015A1-2H Size (mm)90*15*10.1h IMP (ohm)4 Rated Power (W) 5W FO (Hz) 200Hz±20% SPL (dB) 82±3dB (1W/0.5M; Average at 800Hz, 1000Hz, 1200Hz, 1500Hz) |
